SC to FC Single Mode 9/125 Fiber Patch Cord 3m 5m 10m Custom Length
Détails sur le produit:
| Certification: | RoHS, CE, ISO9001, VDE, CCC |
Conditions de paiement et expédition:
| Quantité de commande min: | 10 |
|---|---|
| Prix: | 0.56 |
|
Détail Infomation |
|||
| Structure de connexion: | FC-SC | Forme du matériau: | Fil rond |
|---|---|---|---|
| Pression latérale autorisée: | > 1000 (n / 100 mm) | Autorisation de résistance à la traction: | > 10000N |
| cœur: | Noyau unique | Matériau de gaine: | PVC ou LSZH |
| Type de connecteur: | SC, FC, ST, LC, ODC, IPLC, PDLC, MTRJ, MPO, MTP, MU, SMA | Longueur: | 3m, 5m, 10 ou personnalisé |
| Matériel: | LSZH, PVC, PE, PU | Fibre: | G652D, G655, G657A1, G657A2 |
| Type de fibre: | SM, MILLIMÈTRE | OD de fibre normale: | 125 ± 0,2UM |
| Perte: | 0,2 dB (typique), 0,3 dB (max) | Pertes de rendement: | PC: 50DB, UPC: 55DB, APC: 65DB |
| Température de fonctionnement: | -40 ° C ~ + 85 ° C | ||
| Mettre en évidence: | SC to FC single mode fiber patch cord,9/125 fiber optic cable with warranty,custom length SC FC patch cable |
||
Description de produit
Hotselling SC/UPC to FC/APC Single Mode 9/125 Simplex Optical Fiber Patch Cord
A high-performance fiber optic patch cord designed for reliable signal routing between devices. Features SC to FC/APC connectors with single mode 9/125μm fiber for optimal signal transmission.
Product Details
- SC-SC fiber patch cord configuration
- Subscriber Connector (SC) - general purpose push/pull style connector with square, snap-in design
- Keyed connector latches with simple push-pull motion
Key Features
- Low insertion loss and high return loss
- High density connection with easy operation
- Excellent reliability and stability
- Superior repeatability and exchangeability
Applications
- Testing equipment
- FTTX+LAN networks
- Optical fiber CATV systems
- Optical communication systems
- Telecommunication infrastructure
Performance Specifications
| Parameter | Single Mode | Multimode |
|---|---|---|
| Normal Fiber OD | 125±0.2μm | 125±0.2μm |
| Connector Types | SC, FC, ST, E-2000, LC, MU | MTRJ, SC, FC, ST, E-2000, LC, MU |
| Insertion Loss (Typical) | 0.2dB | 0.4dB |
| Insertion Loss (Max) | 0.3dB | 0.5dB |
| Return Loss (Typical) | PC: 50dB UPC: 55dB APC: 65dB |
35dB |
| Mating Durability (500 cycles) | 0.2dB | |
| Temperature Stability | 0.3dB | |
| Operation Temperature | -40°C to +85°C | |
| Storage Temperature | -40°C to +85°C | |
